Abb Palletizing Robot Price IRB660  Multi-station  Palletizing

The ABB IRB660 is an industrial robot specifically designed for material handling and palletizing applications. It stands out among its peers for its high speed, heavy payload capacity, and long reach. Below is a detailed introduction to the IRB660:

I. Technical Specifications

• Payload Capacity: The IRB660 is available in two versions. One version can handle a payload of 180 kg at full speed, while the other can achieve high-throughput operations with a payload capacity of up to 250 kg.
• Reach: With a reach of 3.15 meters, it can simultaneously operate multiple infeed conveyors, pallet stacks, and outfeed stacking lines.
• Number of Axes: It features a 4-axis design, providing a high degree of flexibility and range of motion.
• Protection Rating: IP67, ensuring stable operation even in harsh environments.
• Controller: Equipped with ABB's versatile IRC5 controller, it supports quick and convenient programming as well as intuitive operation.
• Software: It comes with the comprehensive packaging line software PickMaster, which includes various key functions to optimize production processes.

II. Performance Characteristics

• High-Speed Operation: The IRB660 offers significantly improved operating speeds compared to its predecessor, with optimized motor power and motion performance enabling cycle times that are noticeably shorter than those of competing products.
• High Precision: It boasts a repeatability of 0.1 mm and a repeat cycle accuracy of 0.3 mm, ensuring accurate and stable palletizing.
• Robustness: Designed to be durable and robust, it can withstand long-term, high-intensity operations.
• Flexibility: It can simultaneously operate multiple infeed conveyors and pallet stacks, meeting the needs of multi-station palletizing.

III. Applications

The IRB660 is widely used in material handling, palletizing, packaging, and other fields. It is particularly suitable for handling packaging materials such as bags, boxes, crates, and bottles. Its high speed, heavy payload capacity, and long reach make it an ideal choice for improving production efficiency and reducing labor intensity.

Advantage:

According to many project experience shows that the palletizing robot in the actual project site if the layout is reasonable and proper, it can easily achieve the above-mentioned palletizing efficiency or even exceed, if a palletizing robot corresponds to more than two production lines and multiple palletizing stations, then the overall palletizing efficiency will decrease, and the multi-station palletizing will increase because of the robot's travel. Therefore, the single cycle time becomes longer, which causes the overall palletizing efficiency to decline.
Ways to improve palletizing efficiency:
1. The site layout is reasonable to avoid areas that interfere with the operation of the robot and avoid areas that are inaccessible to the robot and lead to restrictions
2. The fixture or suction cup should be properly designed to reduce redundant movements
3. By optimizing the program, remove unnecessary pauses to make the robot run more smoothly
4. Ensure that the maximum conveying efficiency of the assembly line is greater than the grasping efficiency of the robot
5. Set the cache bit, cache the supply of empty pallets and palletizing the products that have been delivered
6. The fixture or sucker is designed to grab more than one at a time, so that more grab and more release, so that the efficiency of the fixture or sucker is maximized
7. The pipeline at the end of the robot flange should be designed to be able to pass through the center hole of the sixth axis to ensure that the rotation Angle of the robot's sixth axis is above or below 180 degrees without breaking the pipeline package, otherwise it has to reduce the robot's running speed and action mode, resulting in slower robot speed.
8. The end user should remove some unnecessary requirements, such as the label facing out, such as the bag mouth facing in, etc., which can greatly improve the palletizing speed

FAQ:

*Q:Why are we?

A:Our company works robot industry over fifteen years. Programming robot inclusive KUKA ,ABB,YASKAWA,FANUC,ESTUN(Chinese ROBOT ),EFORT(Chinese robot). the business involved simulation,programming,service after warranty period.

*Q:How about our service concept?

A:We keep on phone open all day. Stand in customer view to provide rationalization solution and robot selection.

*Q:What products can we offer?

A:robot, energy supply for robot, linear for robot. Training for robot. Gripper for handling.

*Q:Why you purchase from us?

A:You don’t worry about after-sales problem to cooperation with us.

About us

Companies in the "customer first, quality first, the user first" purpose, we will as always Warm and sincere service for all users, friends and customers, create brilliant tomorrow. Our main customers are Baosteel, INO,Volkswagen,Geely and so on. Over fifteen years experience in the robot industry. Our engineers can design solution,simulation,program and troubleshooting. So if you have any issue of robot. Call us any time. We will try our best to solve the problem. The other advantage is after-sales service,we have robot spare parts in stockroom. We can response promptly to help you resolve robot fault. We also have robot training. The course include programming, electric, mechanic and expert programming. So welcome to join our college.
