Industry Robot Arm Kuka KR60-3 High-performance Six Axis Robot
  • Industry Robot Arm Kuka KR60-3 High-performance  Six Axis Robot
  • Industry Robot Arm Kuka KR60-3 High-performance  Six Axis Robot
  • Industry Robot Arm Kuka KR60-3 High-performance  Six Axis Robot

Industry Robot Arm Kuka KR60-3 High-performance Six Axis Robot

Place of Origin China
Brand Name KUKA
Model Number KR60-3
Product Details
Type::
KUKA Robot KR60-3
Payload::
60kg
Reach::
2033mm
Weight:
665KG
Repeatability::
0.06mm
Number Of Axes::
6axis
Footprint::
850mm X 950mm
Mounting Position:
Floor, Celling,
Controller::
KR C4
Highlight:

High performance Six Axis Robot

,

Industrieroboter Six Axis Robot

,

Kuka KR60-3 Six Axis Robot

Payment & Shipping Terms
Minimum Order Quantity
1PCS
Price
Negotiation
Packaging Details
Original package
Delivery Time
5-12WEEKS
Payment Terms
L/C,T/T
Product Description

Industrieroboter Kuka KR60-3 High-performance  Six Axis Robot

The KUKA KR60-3 is a high-performance six-axis industrial robot designed for medium payload applications. As a classic model in KUKA's robot series, the KR60-3 enjoys an excellent reputation in global industrial automation due to its outstanding precision, reliability, and flexibility. With a maximum payload capacity of 60kg and a working radius of 2035mm.

The KR60-3 features a compact design with a small footprint, making it particularly suitable for factory environments with limited space. Its six-axis structure provides exceptional freedom of movement for complex three-dimensional operations. The robot offers a repeatability of ±0.05mm, ensuring high precision requirements in production processes. Additionally, the KR60-3 delivers impressive speed and acceleration performance, reaching maximum speeds of 2.2m/s, significantly improving production efficiency.

1. Technical Parameters

  • Payload Capacity: 60kg (max 70kg for short distances)

  • Reach: 2.03m (standard), optional 2.4m extended arm

  • Repeatability: ±0.05mm

  • Axes: 6 (full articulation)

  • Protection Class: IP54 (IP67 optional)

  • Cycle Time: 0.45 sec for standard moves

  • Why Manufacturers Choose KR60-3

    ✅ Cost-Effective Automation

    • 40% lower TCO than comparable ABB/FANUC models

    • 2-3 year typical ROI for most applications

    • Low energy consumption (3.5kW average)

    ✅ Proven Reliability

    • 50,000+ hours MTBF (Mean Time Between Failures)

    • Global spare parts availability

    • 10-year+ operational lifespan with proper maintenance

    ✅ Application Flexibility

    ✔ Machine tending (CNC, injection molding)
    ✔ Arc welding (MIG/MAG/TIG)
    ✔ Material handling (packaging, transfer)
    ✔ Assembly operations
    ✔ Surface treatment (painting, polishing)


Advantage:


Service We supply 3d model, foundation and flange dimensions of related robot. Supply training video to fresh customer. The video include of how to mastering,how to connect the cable,how to programming and so on. If you have any problem, call us anytime or sent email to us.
Robot Maintains The robot we suggest maintains every one year or 10000 hours. the main job is exchange oil, fans,UPS and so on. If the robot working in terrible environment, just like low temperature or wet environment. So such case we suggest half year or 5000 hours to do maintains.
Warranty 1 Year


Place of origin: China

Brand Name: KUKA

Model Number: KR60-3


Type: KUKA KR60-3 Reted Payload: 60kg
Reach: 2033mm Repeatability: 0.06mm
Axis: 6 Weight: Approx. 665kg
Mounting Position: Floor , celling Protection Rating: IP65
Footprint:850mm X 950mm Controller: KRC4
Item value
Applicable Industries Hotels, Garment Shops, Building Material Shops, MachineryRepair Shops, Manufacturing Plant, Food & Beverage FactoryFarms, Restaurant, Home Use, Retail, Food Shop, PrintingShops, Construction works , Energy & Mining, Food &Beveraqe Shops, Other, Advertising Company
After Warranty Service Video technical support, Online support
Video outgoing-inspection Provided
Machinery Test Report Provided
Marketing Type Hot Product 2019
Warranty of core components 1 Year
Core Components PLC
Condition New
Place of Origin China
Warranty 1 Year
Service mode Online support
Type KUKA KR60-3
Rated payload 60 kg
Reach 2033mm
Repeatability 0.06mm
Axis 6
Weight Approx. 665kg
Mounting position Floor,Celling
Protection rating IP65
Footprint 850mm X 950mm
Controller KRC4
