Gripper Arm Robot 5 Axes KR 240 R3200 PA Kuka Robot Palletize
The KUKA KR 240 R3200 PA is a high-performance 5-axis robotic arm designed specifically for palletizing applications in industries such as logistics, food & beverage, automotive, and e-commerce. With a payload capacity of 240 kg and a reach of 3,200 mm, this robot excels in handling heavy-duty palletizing tasks with precision, speed, and reliability.
2.1. Primary Industries & Use Cases
- Logistics & Warehousing – Automated palletizing of boxes, cartons, and parcels for efficient storage and shipping.
- Food & Beverage – Handling of cases, bottles, and cans in beverage production lines.
- Automotive – Palletizing of heavy components like engines, transmissions, and body panels.
- Chemical & Pharmaceutical – Safe stacking of drums, sacks, and hazardous materials.
- E-Commerce & Retail – High-speed order fulfillment with mixed-SKU palletizing.
2.2. Advantages Over Manual Palletizing
- 24/7 Operation – Eliminates fatigue-related errors and downtime.
- Consistent Quality – Precise stacking reduces product damage.
- Higher Throughput – Up to 1,200 cycles/hour (depending on payload).
- Space Optimization – Maximizes pallet density for better storage utilization.
- Safety Compliance – Reduces workplace injuries from heavy lifting.
3. Technical Specifications & Performance Metrics
Advantage:
|
Features
|
This series of robot is suitable for palletizing industry. Max.Range is 3195mm. If your pallet size is 1000mm*1200mm,the robot can cover up to 6 pallets. Just like simulation describes. The other advantage is robot cycle time. Up to stacking 800 bags one hour. So if your application is palletizing. We suggest you select this series robot. |
| Service |
We supply 3d model, foundation and flange dimensions of related robot. Supply training video to fresh customer. The video include of how to mastering,how to connect the cable,how to programming and so on. If you have any problem, call us anytime or sent email to us. |
| Robot Maintains |
The robot we suggest maintains every one year or 10000 hours. the main job is exchange oil, fans,UPS and so on. If the robot working in terrible environment, just like low temperature or wet environment. So such case we suggest half year or 5000 hours to do maintains. |
| Warranty |
1 Year |
Place of origin:China
Brand Name: KUKA
Model Number: KR240 R3200PA
| Type: KUKA KR 240 R3200 PA |
Reted Payload: 240kg |
| Reach: 3195mm |
Repeatability: 0.06mm |
| Axis: 5 |
Weight: Approx. 1103kg |
| Mounting Position: Floor |
Protection Rating: IP65 |
| Footprint:830mm X 830mm |
Controller: KRC4 |
| Item |
value |
| Applicable Industries |
Hotels, Garment Shops, Building Material Shops, MachineryRepair Shops, Manufacturing Plant, Food & Beverage FactoryFarms, Restaurant, Home Use, Retail, Food Shop, PrintingShops, Construction works , Energy & Mining, Food &Beveraqe Shops, Other, Advertising Company |
| After Warranty Service |
Video technical support, Online support |
| Video outgoing-inspection |
Provided |
| Machinery Test Report |
Provided |
| Marketing Type |
Hot Product 2019 |
| Warranty of core components |
1 Year |
| Core Components |
PLC |
| Condition |
New |
| Place of Origin |
China |
| Warranty |
1 Year |
| Service mode |
Online support |
| Type |
KUKA KR 240 R3200 PA |
| Rated payload |
240 kg |
| Reach |
3195mm |
| Repeatability |
0.06mm |
| Axis |
5 |
| Weight |
Approx. 1103kg |
| Mounting position |
Floor |
| Protection rating |
IP65 |
| Footprint |
830mm X 830mm |
| Controller |
KRC4 |
